Kasli is a powerful FPGA controller that serves as the heart of the Sinara Open Hardware project. It is capable of controlling up to 12 Eurocard extension modules (EEMs), making it a versatile platform for a wide range of experiments.
Kasli is based on a Xilinx Artix-7 FPGA, which balances costs and range of applicability. To meet requirements of the target domains, Kasli is equipped with a circuitry for high quality clock generation with onboard oscillator and external reference input for extended clock stability.
With 4 SFP sockets available, it can connect to the network with RJ45 adapter and serve as a master for 3 satellite modules at the same time. It is also possible to use SFPs with PCIe x4 link for increased data throughput.
Main features
- AMD Artix-7 FPGA
- 12 EEM peripheral slots
- 512 MB DDR3 SDRAM
- SPI Flash for FPGA configuration
- Clocking circuitry for DRTIO / WR with external reference input
- 4 MMCX clock outputs for internal connectivity to EEM peripherals
- 4 SFP connectors for Ethernet, DRTIO and other data links
- MicroUSB for flashing and debugging
Software support
Scheme
Error: Contact form not found.
Resources
Applications
- ARTIQ – full support for all onboard features.
- AMD Vivado / Vitis – only constraints available at the moment
