The SPEC-A7 is a PCIe carrier board, designed for deterministic, low-jitter communication in time-critical systems.

Kasli is the most widely used FPGA-based ARTIQ controller, connecting up to 12 EEMs with flexible clocking and external connectivity options.

Kasli SoC is the new SoC-based ARTIQ controller, connecting up to 12 EEMs with flexible clocking and external connectivity options.

Sampler is a high-precision, multi-channel analog-to-digital converter (ADC) module designed for demanding scientific experiments and real-time data acquisition.

Zotino is a 32-channel, 16-bit DAC EEM with an update rate of 1MSPS (divided between the channels arbitrary). It was designed for low noise and good stability.

Fasatino is a 32-channel, 16-bit DAC EEM with an update rate of 3 MSPS (divided between the channels arbitrary). It was designed for low noise and good stability.

Urukul is a 4 HP EEM card that works as a 4-channel wide range frequency synthesizer. It extends the capabilities of Kasli carrier card supported by ARTIQ.

HVAmp 8ch is EEM module working as an 8-channel high voltage amplifier initially dedicated to large ion traps. It allows amplify signal to +/-200 V output range in 1 MHz bandwith with power limited by slew rate at the level 30 V/μs and cable capacitance.
